360 Around-view Assist System

Current:Home>Products>   360 Around-view Assist System

MT-QJ8302RI C Class 2013


Item No.:MT-QJ8302RI

Application:Mercedes-Benz C 2013
Previous      Next
Product Information
Applications: Mercedes-Benz C 2013
Product features:
  • Built-in decoder and ipas (built-in navigation is optional)
  • LVDS video insertion
  • Factory protocol handling, when driving the car, after turning left or right, you won't see the camera image, so make your driving more safe
  • Plug-and-play, reversing, left/right turning signal output from decoder box, no need to  connect the cables again
  • Defending the vibration function


Technical parameters:

  • Image device: 3089
  • Image area: 1/3 inches
  • Pixel dimensions: 6.35*7.4um
  • Effective pixel: 720H*480V
  • Horizontal resolution: 580TV lines
  • Video format: PAL/NTSC
  • Signal to noise: >48dB
  • Dynamic range: >72dB
  • Automatic electronic exposure: electronic rolling shutter
