360 Around-view Assist System

Current:Home>Products>   360 Around-view Assist System

MT-QJ8103RI VW Magotan


Item No.:MT-QJ8103RI

Application:2013 VW Magotan
Previous      Next
Product Information
Application:2013 VW Magotan
Product features:
Built-in decoder and ipas (built-in navigation is optional)
LVDS video insertion
Factory protocol handling, when driving the car, after turning left or right, you won't see the camera image, so make your driving more safe
Plug-and-play, reversing, left/right turning signal output from decoder box, no need to  connect the cables again
Defending the vibration function

Technical parameters:
Image device: 3089
Image area: 1/3 inches
Pixel dimensions: 6.35*7.4um
Effective pixel: 720H*480V
Horizontal resolution: 580TV lines
Video format: PAL/NTSC
Signal to noise: >48dB
Dynamic range: >72dB
Automatic electronic exposure: electronic rolling shutter
Minimum illuminance: 0.1 lux
Video Output:1.0VP-P/75Ω
Horizontal angle:170°
